Description
Product Overview
The GE DS200TCPDG1BEC is a professional industrial DC power distribution board. It belongs to the GE Mark V turbine control system series. It acts as the core power distribution and protection unit for power generation control cabinets.
This module stabilizes and distributes system power for internal control boards. It provides safe and regulated power supply for I/O modules and communication units. It integrates fuses and toggle switch components. It realizes overcurrent protection and circuit management. Adopting industrial PCB coating design, it adapts harsh power plant environments. It is widely used for system matching, faulty board replacement and power system maintenance.
Core Product Features
The GE DS200TCPDG1BEC adopts dedicated turbine power distribution architecture. It solves unstable power supply and poor circuit protection of ordinary power boards. It ensures long-term safe power supply for control systems.
- Stable Power Distribution: It distributes DC power evenly to multiple system modules. It maintains consistent voltage for turbine control units.
- Integrated Circuit Protection: Built-in multiple fuses and switch groups. It cuts off faulty circuits quickly to avoid equipment damage.
- Real-Time Fault Isolation: It isolates single-point circuit faults effectively. It prevents fault spread and protects the whole control cabinet.
- Industrial Anti-Corrosion Design: Standard PCB protective coating. It resists dust, moisture and slight chemical corrosion.
- High Electromagnetic Compatibility: Optimized circuit layout. It resists on-site electromagnetic interference in power plants.
- Easy On-Site Maintenance: Equipped with independent toggle switches. It supports single-channel power cut and quick troubleshooting.
- 24/7 Full-Load Operation: Industrial-grade components support continuous power supply. It features low loss and high stability.
Detailed Technical Specifications
All technical parameters comply with GE Mark V industrial control standards. Each board passes strict power testing and aging screening before factory delivery.
- Official Model: DS200TCPDG1BEC
- Product Type: Industrial DC Power Distribution Board
- Applicable System: GE Mark V Turbine Control System
- Core Function: System power distribution, overcurrent protection, circuit isolation, power stability control
- Rated Input Voltage: Standard industrial DC power supply
- Built-In Configuration: Multiple fuses and manual toggle switches
- Protection Mechanism: Overcurrent protection, short-circuit isolation, voltage surge suppression
- Surface Treatment: Industrial PCB anti-corrosion coating
- Operating Temperature Range: -20°C to +70°C
- Storage Temperature Range: -40°C to +85°C
- Working Humidity: 5%–95% RH, non-condensing environment
- Installation Method: Standard cabinet plug-in installation
- Continuous Operation: Support 7×24 hours full-load uninterrupted operation
- Industrial Certification: CE, UL and EMC electromagnetic compatibility certification
Main Application Fields
This industrial power distribution board focuses on power supply guarantee for turbine control systems. It provides safe and stable power support for key power equipment.
- Thermal Power Turbine Control: It supplies stable power for gas turbine and steam turbine control cabinets. It ensures normal operation of core control boards.
- Power Plant DCS System: It undertakes internal power distribution of distributed control systems. It improves overall power supply stability.
- Industrial Power Automation: It applies to industrial power distribution control cabinets. It protects system circuits and reduces power failure risks.
- Old System Renovation & Upgrade: It replaces aging power distribution boards. It optimizes system power supply efficiency and safety performance.
- Power Plant Spare Part Reserve: It serves as key power system spare board. It quickly replaces faulty units and reduces equipment downtime.
Related Model Recommendations
The following Mark V series models are fully compatible with DS200TCPDG1BEC. They meet system replacement and functional matching requirements.
- DS200TCPDG2BEC: Upgraded power distribution board. It supports higher voltage and wider power supply range for large turbine systems.
- DS200TCEAH1B: Turbine control auxiliary board. It cooperates with power distribution boards to complete system power and signal matching.
- DS200DTBCF1A: System signal processing board. It works steadily with power modules to ensure normal signal transmission.
- DS200TCPSG1A: System power supply board. It forms a complete power supply system with DS200TCPDG1BEC.
IS220PDIOH1A 8507-BI-DP DS200DCFBG2BNC DS200FSAAG1ABA DS200PCCAG5ACB DS200TCQCG1AJD DS3800XTFP1E1C
