Description
- Model: 3500/22-01-01-05
- Brand: Bently Nevada (Baker Hughes)
- Series: 3500 Machinery Protection System Series
- Core Function: Transmits transient data and manages system communication stably
- Type: Transient Data Interface Module (TDI)
- Key Specs: High-speed 2kHz sampling rate, RS-485 & Ethernet communication, industrial grade isolation
- Supply Status: In stock
- Stock: Available
- Warranty: 1 year
- Ship From: China
Bently Nevada 3500/22-01-01-05
Product System Overview
The Bently Nevada 3500/22-01-01-05 is a core transient data interface module belonging to the industry-leading 3500 machinery protection system, a mature and globally verified monitoring platform launched by Baker Hughes. As a mandatory rack-level core component, this TDI module is fixedly installed in the first slot of the 3500 system rack, cooperating with power supply modules, monitoring cards and relay modules to form a complete closed-loop machinery condition monitoring system. It acts as the critical data bridge between the 3500 hardware rack and upper monitoring software, System 1 diagnostic platform, and factory DCS/SCADA systems. Fully compliant with API 670 industrial standards and supporting SIL safety grade configuration, the entire system realizes unified data collection, logic judgment and remote transmission. Widely deployed in global heavy industrial sites for decades, it serves as the standard hardware solution for rotating machinery safety protection and predictive maintenance.
Core Product Functions
This 3500/22 TDI module undertakes high-speed transient data acquisition and real-time communication management for the entire monitoring rack. It efficiently collects vibration, displacement, temperature and speed data collected by all front-end monitoring modules, and transmits complete waveform data, trend data and fault event records to upper computers for real-time display and storage. It supports high-precision 2kHz high-speed sampling, which can capture instantaneous transient faults and subtle vibration mutations that ordinary modules cannot identify, providing complete data basis for equipment fault diagnosis. In addition, it realizes remote system configuration, parameter modification and program debugging, allowing engineers to remotely calibrate monitoring thresholds and optimize system logic. It also synchronizes alarm and trip signal output status, ensuring linkage feedback between the monitoring system and on-site safety interlock equipment, effectively avoiding major equipment failures and unplanned shutdown risks.
Bently Nevada 3500/22-01-01-05
Product Features & Technical Advantages
The 3500/22-01-01-05 module boasts outstanding industrial adaptability and operational stability. Firstly, it adopts dual high-speed communication design with RS-485 and Ethernet interfaces, supporting multiple industrial protocols to ensure stable and low-delay data transmission. The built-in hardware isolation and electromagnetic shielding structure effectively resist strong electromagnetic interference, vibration and temperature fluctuation in turbine workshops and chemical plants, maintaining long-term error-free operation. Secondly, it supports full rack data synchronization and centralized management, greatly simplifying system wiring and later maintenance work. With intelligent data filtering and sorting functions, it automatically screens valid monitoring data and suppresses clutter interference, improving data accuracy. The standardized plug-and-play design enables fast disassembly and replacement, reducing equipment downtime. Moreover, it supports redundant system configuration and TMR logic judgment, effectively preventing false trips and missed trips, significantly improving the overall safety and reliability of industrial machinery protection systems.
Industrial Application Scenarios
This professional transient data interface module is widely used in high-reliability industrial scenarios requiring rotating machinery online monitoring and safety protection. It is mainly applicable to large steam turbines, gas turbines, centrifugal compressors and high-speed rotating equipment in thermal power plants, combined cycle power stations, petrochemical and oil & gas industries. It also serves key production equipment in metallurgy, pharmaceutical manufacturing and large water treatment plants. As the core data transmission hub of the 3500 system, it ensures real-time, accurate and stable operation of the entire machinery monitoring system, helping enterprises realize predictive equipment maintenance, reduce maintenance costs and guarantee continuous and safe operation of production equipment.
