Description
- Model: 3500/22M 138607-01
- Brand: BENTLY (Bently Nevada, a Baker Hughes company)
- Series: BENTLY 3500 Series Condition Monitoring System
- Core Function: Transient data collection and transmission for 3500 system
- Type: Transient Data Interface (TDI) Module
- Basic Introduction: High-precision TDI module for BENTLY 3500 monitoring system, connecting to host software for data analysis.
- Key Application: Collect steady-state and transient data, transmit to host software for fault diagnosis.
- System Compatibility: Seamlessly integrates with BENTLY 3500 system and System 1 condition monitoring software.
BENTLY 3500/22M 138607-01
Product Specifications
- Model: 3500/22M 138607-01
- Type: Transient Data Interface (TDI) Module
- Brand: BENTLY (Bently Nevada, a Baker Hughes company)
- Series: BENTLY 3500 Series Condition Monitoring System
- Power Supply: 24 VDC (18-30 VDC, typical)
- Power Consumption: Max 6 W
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +85°C
- Working Humidity: 5% to 95% (non-condensing)
- Communication Interface: 10Base-T/100Base-TX Ethernet
- Communication Protocol: TCP/IP
- Data Collection: Steady-state and transient waveform data
- Installation Position: Slot 1 of BENTLY 3500 rack (near power supply)
- Dimensions: 4.4 cm × 7.6 cm × 15.2 cm
- Shell Material: Industrial-grade metal
- Certifications: CE, RoHS
Product Features
- High-Precision Data Collection: Captures high-resolution transient and steady-state data for accurate fault analysis.
- Specialized TDI Function: Combines RIM (Rack Interface Module) and communication processor functions for integrated data management.
- Fast Ethernet Transmission: 10Base-T/100Base-TX Ethernet ensures stable and high-speed data transfer to host software.
- Wide Operating Range: -40°C to +85°C adapts to extreme industrial environments like oilfields and power plants.
- Flexible Configuration: Optional channel-enabled disk supports high-resolution transient data capture.
- Easy Integration: Perfectly matches BENTLY 3500 rack and M-series monitors (3500/40M, 3500/42M).
- High Reliability: Industrial-grade design with strong anti-interference ability, suitable for long-term continuous operation.
- Non-Critical Path Design: Does not affect the normal operation of the 3500 system’s automatic mechanical protection function.
- Programmable Function: Supports custom programming of logic functions and control strategies to meet diverse application needs.
- User-Friendly Operation: Equipped with touch panel for real-time data display and easy parameter configuration.
BENTLY 3500/22M 138607-01
Product Uses
- Transient Data Collection: Continuously collects steady-state and transient waveform data from 3500 monitoring system.
- Data Transmission: Transmits collected data to System 1 mechanical management software for analysis and processing.
- Fault Diagnosis: Provides high-precision data support for early detection of rotating machinery faults (vibration, imbalance, etc.).
- System Connection: Acts as a bridge between BENTLY 3500 monitoring system and host software for seamless data exchange.
- Pulse Control & Counting: Suitable for high-precision pulse control and counting applications in industrial scenarios.
- Equipment Monitoring: Assists in monitoring rotating machinery (pumps, compressors, turbines) and static equipment status.
- Predictive Maintenance: Provides data basis for predictive maintenance to reduce unplanned downtime.
Application Fields
- Power Generation: Generator, steam turbine and hydro turbine condition monitoring and fault diagnosis.
- Oil & Gas: Drilling equipment, compressors and turbines monitoring in on-site operations.
- Petrochemical Industry: Centrifugal compressors, pumps and gearboxes status monitoring.
- Metallurgy: Rolling mills, fans and other heavy rotating machinery condition monitoring.
- Manufacturing: High-speed rotating equipment monitoring in machining and processing lines.
- Paper Industry: Paper production equipment condition monitoring and fault prediction.
- Mining: Mining machinery and auxiliary equipment status monitoring and data transmission.
- Aerospace: Engine and transmission system high-precision vibration analysis.
BENTLY 3500/22M 138607-01
New-Old Model Comparison (3500/22M 138607-01 vs 3500/22M 288055-01)
- Model & Product Type: Both models are Transient Data Interface (TDI) Modules of BENTLY 3500 Series; Old model: 3500/22M 138607-01; New model: 3500/22M 288055-01.
- Core Function: Both focus on transient/steady-state data collection & transmission; New model supports higher-speed data transmission and more complex transient event processing.
- Communication Interface: Old model only supports 10Base-T/100Base-TX Ethernet; New model adds USB-B front panel and 100Base-FX fiber optic Ethernet for more connection options.
- Channel Capacity: Old model has basic channel support; New model can handle up to 48 channels to meet complex monitoring needs.
- Power Consumption: Old model has max 6W power consumption; New model has higher power consumption (10.5W) due to enhanced functions.
- Data Processing: Old model supports optional high-resolution transient data capture; New model has advanced signal processing capability and higher sampling rate to capture subtle vibration changes.
- Frequency Bandwidth: Old model has standard frequency bandwidth; New model supports up to 500 kHz frequency band for wider monitoring range.
- Protection Level: Old model has no special protection level mentioned; New model reaches IP67 protection level, more suitable for harsh environments.
- Dimensions & Weight: Old model is 4.4 cm × 7.6 cm × 15.2 cm, approx. 0.3-0.4kg; New model is larger (24.18mm x 2.44mm x 24.13mm) and heavier (approx. 0.5-1.6kg).
- Application Focus: Both apply to transient data analysis & fault diagnosis; New model is more suitable for large-scale, complex industrial monitoring scenarios such as oil & gas and power generation.
