Description
Product Overview
The GE VMIVME-7697-850 is a high-performance industrial VMEbus single-board computer (SBC) developed for rugged embedded control systems. Powered by an Intel Pentium III 850 MHz processor, this 6U dual-slot VME board serves as the core computing unit for industrial rack-based control systems. It integrates on-board memory, graphics processing, multi-channel I/O interfaces and bus bridging functions. It delivers stable and reliable computing power for industrial automation, aerospace, defense and large-scale process control equipment. As a classic upgraded model in the GE VMIC series, it solves the low-speed and unstable operation problems of early-generation VME bus boards.
Traditional industrial single-board computers often face performance bottlenecks in long-term high-load operation. Most ordinary VME boards have low main frequency, limited memory expansion capacity and single interface configuration. They cannot support complex algorithm operation and multi-task concurrent processing. In addition, generic boards suffer from poor temperature resistance and weak anti-interference ability in harsh industrial environments. These defects easily cause system crash, data loss and program operation errors. In contrast, the GE VMIVME-7697-850 adopts low-power split-voltage industrial design and high-standard component selection. It balances high computing performance and long-term operational stability. Each board passes strict high-low temperature aging, vibration testing and full-function calibration before factory delivery. It has become a mainstream core board for industrial system upgrading, old equipment renovation and global industrial e-commerce standardized procurement.
Core Product Features & Competitive Advantages
Embedded industrial control systems require stable computing performance, strong environmental adaptability and excellent bus compatibility. Ordinary civilian-grade main boards cannot meet the 7×24-hour uninterrupted operation requirements of industrial equipment. Different from universal single-board computers, the GE VMIVME-7697-850 is specially optimized for VME bus industrial scenarios. It combines high-frequency processor performance, rich expansion interfaces and industrial-grade rugged design. It greatly improves the operational efficiency and stability of industrial control systems.
- High-Frequency Industrial Processor Performance: Equipped with Intel Pentium III 850 MHz high-speed processor. It supports multi-task concurrent operation and complex industrial control algorithm processing. It meets the high-speed computing demands of industrial real-time control and data analysis.
- Flexible On-Board Memory Configuration: Standard 128 MB on-board SDRAM, supporting maximum 512 MB memory expansion. The dual-ported memory design realizes efficient data interaction between local processor and VME bus. It effectively improves data transmission efficiency.
- Integrated Graphics & Multimedia Function: Built-in 64-bit AGP SVGA graphics accelerator. It supports industrial display output and on-site visual monitoring. It meets the display and human-computer interaction needs of industrial control equipment without additional graphics cards.
- Complete Rich Expansion Interfaces: It integrates multiple universal industrial interfaces, including keyboard and mouse interfaces, Ultra-IDE hard disk interface, floppy drive interface and serial communication ports. It supports flexible peripheral equipment docking and function expansion.
- Professional VME Bus Compatibility: Adopts standard 6U dual-slot VMEbus architecture. It is fully compatible with mainstream VME rack systems and expansion modules. It supports plug-and-play replacement and seamless system upgrading.
- Low-Power Industrial Design: Optimized split-voltage power supply architecture reduces operating power consumption and heat generation. It avoids system instability caused by overheating during long-term full-load operation. It improves continuous operation reliability.
- Rugged Environmental Adaptability: Industrial-grade component selection and anti-vibration structural design. It adapts to harsh working conditions such as temperature fluctuation, mechanical vibration and electromagnetic interference. It ensures stable operation in industrial and aerospace scenarios.
- Complete On-Board Auxiliary Functions: Equipped with battery-backed clock calendar, front-panel reset switch and miniature speaker alarm. It facilitates on-site equipment debugging, status monitoring and fault prompt.
- Multi-System Compatibility: It supports mainstream industrial operating systems including Windows XP, Linux and VxWorks. It adapts to different industrial control software platforms and application scenarios.
- Long Service Life & Low Maintenance Cost: Strict factory testing and industrial anti-aging design extend board service life. It features low field failure rate and simple daily maintenance. It reduces enterprise equipment operation and replacement costs.
GE VMIVME-7697-850
Detailed Segmented Technical Specifications
The GE VMIVME-7697-850 strictly complies with GE industrial manufacturing standards and VME bus international industrial specifications. All computing performance, hardware configuration, electrical indicators and environmental resistance capabilities pass professional laboratory testing and long-term field verification. The classified detailed parameters below support accurate model selection, engineering design and standardized batch procurement.
3.1 Basic Product & Application Parameters
The GE VMIVME-7697-850 is a high-performance 6U VME bus industrial single-board computer. It is widely used in core computing and control links of various rugged industrial embedded systems.
- Official Product Model: VMIVME-7697-850
- Product Category: 6U VMEbus Industrial Single Board Computer
- Manufacturer: General Electric (GE / GE FANUC / Abaco Systems)
- Core Processor: Intel Pentium III 850 MHz industrial dedicated processor
- Board Structure: Standard 6U dual-slot VME bus design
- Core Functions: Industrial system core computing, real-time task processing, peripheral equipment management, bus data interaction and graphical display output
- Applicable Systems: VME bus industrial control rack systems, embedded automation control systems and aerospace industrial equipment
- Operating System Support: Windows XP, Linux, VxWorks industrial mainstream systems
- Application Scenarios: Industrial automation control, aerospace equipment, defense industry, power generation control system upgrading and old VME board replacement
- Executive Standards: VME bus international industrial standards, GE original factory technical specifications and industrial EMC electromagnetic compatibility standards
3.2 Core Hardware & Performance Parameters
Hardware configuration directly determines the computing capacity and operational performance of the single-board computer. The GE adopts high-standard industrial hardware matching to ensure efficient and stable system operation.
- Main Processor: Intel Pentium III 850 MHz high-speed industrial processor
- Standard Memory Configuration: 128 MB on-board SDRAM
- Maximum Memory Expansion: Up to 512 MB SDRAM support
- Memory Feature: Dual-ported memory design for efficient VME bus data interaction
- Graphics Processing Unit: Built-in 64-bit AGP SVGA graphics accelerator
- On-Board Storage Interface: Ultra-IDE hard disk interface and floppy drive interface
- Basic Peripheral Interfaces: Standard keyboard, mouse and serial communication ports
- Auxiliary Configuration: Battery-backed real-time clock, front reset button and status alarm speaker
3.3 Electrical & Power Parameters
Standard industrial power supply design ensures stable power operation of the board in complex industrial power grid environments. It avoids system anomalies caused by power fluctuation.
- Working Power Supply: Standard industrial ±12 VDC power supply
- Working Current: 50 mA typical current, maximum 75 mA load current
- Power Supply Tolerance: ±5% voltage fluctuation adaptive range
- Power Design: Low-power split-voltage architecture, low heat generation and high energy efficiency
- Circuit Protection: Built-in over-voltage, over-current and short-circuit protection mechanisms
3.4 Mechanical & Installation Parameters
The board adopts standardized industrial VME structure. It features precise size, firm installation and strong compatibility, perfectly matching standard industrial VME rack installation specifications.
- Board Specification: Standard 6U dual-slot VME bus board
- Installation Method: Industrial standard VME rack plug-in fixed installation
- Structural Design: Reinforced anti-vibration industrial structure
- Layout Feature: Compact integrated layout, supporting intensive rack installation
3.5 Environmental Adaptability Parameters
To adapt to extreme industrial working conditions, the GE passes strict environmental simulation tests. It maintains full-performance stable operation in complex temperature, humidity and vibration scenarios.
- Operating Temperature Range: 0°C to +55°C (300 LFM forced air cooling condition)
- Storage Temperature Range: -40°C to +85°C ultra-wide temperature resistance
- Working Humidity Range: 10%–90% RH non-condensing humid environment adaptation
- Environmental Resistance: Resists mechanical vibration, industrial dust and strong electromagnetic interference
- Continuous Operation: Supports 7×24-hour long-term full-load industrial operation
3.6 Factory Testing & Quality Certification
Every GE single-board computer is manufactured under strict industrial quality control standards. All products complete full-function testing and precision calibration before delivery to meet high-reliability industrial application requirements.
- Core Testing Items: Processor performance test, memory stability test, interface function verification, high-low temperature cycle test and long-term aging test
- Quality Inspection Standard: 100% full-function test + full performance calibration + complete test data filing
- Authoritative Certification: Industrial EMC electromagnetic compatibility certification and industrial safety qualification certification
- Field Reliability: Widely deployed in global industrial and aerospace embedded systems with ultra-low failure rate
GE VMIVME-7697-850
E-commerce Sales Mode & Complete Procurement Advantages
As a core high-performance VME bus industrial single-board computer, the GE adopts standardized, transparent and efficient global industrial e-commerce sales mode. It focuses on industrial embedded system maintenance, old VME equipment upgrading and aerospace/industrial enterprise strategic spare parts reserve. It provides one-stop standardized procurement and full-cycle professional technical services for industrial engineering integrators and high-end equipment manufacturing enterprises.
4.1 Standardized Transparent E-commerce System
All GE products adopt unified original factory production and full-process standardized testing. The whole production, performance calibration and warehousing process is fully traceable. E-commerce platforms openly display complete product datasheets, hardware test reports and official qualification certificates. Customers can verify product authenticity, hardware configuration accuracy and system matching performance online. This transparent sales mechanism effectively avoids refurbished and inferior boards. It fully guarantees the stable and reliable operation of industrial embedded control systems.
4.2 Diversified Flexible Procurement Modes
Industrial equipment emergency maintenance, daily spare parts stocking and large-scale engineering renovation have different procurement cycle and quantity demands. To cover all application scenarios, we provide flexible multi-dimensional procurement solutions for the GE .
- Emergency Spot Procurement: Suitable for on-site single-board computer failure and emergency replacement. Sufficient global spot inventory supports fast delivery. It helps enterprises quickly restore industrial system computing functions and avoid equipment shutdown losses.
- Small-Batch Spare Parts Stocking: Ideal for industrial enterprises and research institutions to build core board spare parts inventory. Pre-storing this product improves on-site fault response speed and reduces equipment operational risks.
- Large-Batch Engineering Procurement: Provide exclusive preferential pricing and long-term framework cooperation services for large-scale industrial system upgrading and embedded equipment renovation projects. It effectively reduces overall project procurement costs and shortens system commissioning cycles.
4.3 Full-Cycle After-Sales Service Guarantee
The industrial single-board computer is the core computing carrier of embedded control systems. Its operational stability directly determines the normal operation of the entire industrial equipment. We provide comprehensive full-cycle after-sales protection to eliminate all customer procurement risks.
- 100% Original Genuine Guarantee: All boards are brand-new original GE products with complete factory test reports and qualification documents, ensuring 100% hardware integrity and system compatibility.
- Professional Industrial Packaging: Adopt multi-layer anti-static, shockproof and moisture-proof packaging. It protects precision on-board chips and circuits from damage during long-distance transportation and storage.
- 24/7 Professional Technical Support: Provide pre-sales model matching consultation, in-sales installation and system docking guidance, and after-sales fault diagnosis, debugging and maintenance services.
- Long-Term Official Warranty Service: Enjoy unified official warranty coverage. Free maintenance and replacement services are provided for non-human-induced quality faults to reduce enterprise operation and maintenance costs.
Main Industrial Application Scenarios
Relying on its high-frequency computing performance, rich interface expansion, excellent bus compatibility and industrial-grade rugged design, the GE is widely used in core computing links of various high-reliability embedded industrial systems.
- Industrial Automation Control System: Serves as the core computing board of VME bus automation racks. It supports real-time operation of industrial control programs and multi-device coordinated control.
- Aerospace & Defense Equipment: Applied to rugged embedded control equipment in aerospace and defense fields. It adapts to harsh environmental requirements and ensures high-reliability operation of precision equipment.
- Power Generation Control System Upgrading: Replaces aging low-performance VME boards in power plant control systems. It improves system computing speed and operational stability without large-scale hardware reconstruction.
- High-End Industrial Embedded Equipment: Used in intelligent detection equipment and process control systems. It provides stable computing support for complex data processing and visual monitoring functions.
Product Value & Market Competitiveness
The GE solves common industry pain points of traditional VME bus single-board computers, such as low main frequency, insufficient memory expansion, single function and poor environmental adaptability. It integrates high-speed processor computing, dual-ported high-efficiency memory, integrated graphics processing and multi-functional peripheral expansion. It greatly improves the computing efficiency, functional integrity and operational stability of industrial embedded systems.
In the global industrial embedded parts e-commerce market, the GE has outstanding comprehensive competitiveness. It features classic mature industrial architecture, wide system compatibility, strong rugged performance and low long-term maintenance cost. Combined with standardized genuine procurement, complete qualification documents and full-cycle professional after-sales services, it is the preferred core computing board for industrial VME system maintenance, intelligent upgrading and enterprise strategic spare parts reserve.
