Description
Product Overview
- Model: TRICONEX 3009 (MP3009)
- Brand: Triconex (Schneider Electric, former Invensys)
- Series: TRICON TMR Fault-Tolerant Control Series
- Core Function: TMR-based safety logic processing
- Type: CPU Module (Enhanced Main Processor Module)
- Basic Introduction: Core CPU for TRICON fault-tolerant safety systems.
- Key Application: Executes safety logic in critical industrial processes.
- System Compatibility: Seamlessly integrates with TRICON CX platform.
TRICONEX 3009
Product Parameters & Specifications (Table)
| Parameter | Specification |
|---|---|
| Model | TRICONEX 3009 (MP3009) |
| Module Type | Enhanced Main Processor Module (UMP/CPU) |
| Brand | Triconex (Schneider Electric, former Invensys) |
| Series | TRICON TMR Fault-Tolerant Control Series |
| Processor | 32-bit RISC (100 MIPS), dual-core high-performance |
| Memory | 8MB Program Memory, 4MB Data Memory |
| Communication Interfaces | 2×Gigabit Ethernet, 2×RS-232, 1×USB |
| Supported Protocols | Modbus TCP/IP, OPC UA, DNP3 |
| Redundancy Architecture | Triple Modular Redundancy (TMR), 2oo3 voting |
| Power Supply | 24 VDC (±10%), Max Power Dissipation 15W |
| I/O Capacity | 1000 analog I/O points, 2000 digital I/O points |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +85°C |
| Protection Class | IP67 (dustproof, waterproof, vibration-resistant) |
| Dimensions (H×W×D) | 259 × 160 × 79 mm (10.2×6.3×3.1 inches) |
| Weight | Approx. 1.13 kg (2.5 lbs) |
| Safety Rating | IEC 61508 SIL3, PL e (ISO 13849-1) |
| Certifications | CE, FM, ATEX, RoHS |
TRICONEX 3009
Product Features
- TMR Fault Tolerance: Triple modular redundancy, 2oo3 voting for high availability.
- High Performance: 32-bit RISC processor, 100 MIPS for fast logic execution.
- Enhanced Processing: Dual-core design supports complex control algorithms.
- Multi-Protocol Support: Compatible with Modbus TCP/IP, OPC UA, DNP3.
- Large I/O Capacity: Supports 1000 analog and 2000 digital I/O points.
- Hot-Swappable: Enables on-line replacement without system shutdown.
- Advanced Diagnostics: Real-time fault detection and SOE recording (≤40ms).
- Harsh Environment Adaptation: IP67 protection and wide temperature range.
- Easy Integration: Seamlessly fits TRICON CX and TRICON series systems.
- Secure Communication: Complies with industrial network security standards.
Product Uses
- Core Logic Processing: Executes safety logic and control programs in SIS.
- Redundancy Management: Maintains system operation during single-point faults.
- Data Processing: Handles real-time industrial data and sensor signals.
- System Communication: Connects with I/O modules, HMI and SCADA systems.
- Safety Interlock: Triggers emergency shutdown (ESD) and BMS functions.
- Fault Diagnosis: Monitors system status and records fault events.
- System Expansion: Supports on-demand I/O module expansion.
TRICONEX 3009
Application Fields
- Oil & Gas: Wellhead control, pipeline ESD, offshore platform safety systems.
- Petrochemicals: Reactor control, distillation unit safety interlocks.
- Power Generation: Turbine control, boiler protection, nuclear safety systems.
- Mining & Metals: Conveyor control, crusher safety, smelting process control.
- Chemical Industry: High-pressure equipment control, leakage prevention.
- Pharmaceuticals: Clean process control, batch production safety systems.
- Fire & Gas Systems: Integration with F&G systems for emergency response.
- Metallurgy: Blast furnace, converter, continuous casting control systems.
