GE VMIVME-7455 Product Description
Product Overview
The GE VMIVME-7455 is a 6U single-slot VMEbus IDE CD-ROM drive module designed for VME-based embedded control and computing systems. It provides compact, integrated optical storage and read capability for VME single-board computers (SBCs) over the VME P2 backplane interface.
This module integrates a slim-line IDE CD-ROM drive into a standard VME 6U form factor. It supports common optical disc formats including CD-ROM, CD-R, CD-RW and multi-session discs, enabling software loading, firmware upgrade, data archiving and program distribution for industrial control systems. Built with conformal-coated circuitry and rugged mechanical design, it operates reliably in industrial, power generation and aerospace test environments.
GE VMIVME-7455
Core Product Features
- Single 6U VMEbus slot design saves valuable chassis space while adding CD-ROM storage to embedded systems.
- 24X or faster CD-ROM read speed with IDE burst transfer rates up to 16 MB/s for efficient data access.
- Connects to host VME SBCs through the standard P2 backplane connector, requiring no additional cabling inside the chassis.
- Supports CD-ROM, CD-R, CD-RW, multi-session, Enhanced CD and CD PLUS disc formats for broad software compatibility.
- Ultra-low power draw: less than 0.8 W at idle and 7 W maximum during active disc read operations.
- Conformal coated PCB resists humidity, dust and corrosion for deployment in harsh industrial and shipboard environments.
- Front-panel disc ejection slot allows quick media changes without removing the module from the chassis.
- Meets MIL-STD-810 shock and vibration ratings and industrial EMC standards for rugged embedded use.
Technical Specifications
| Item | Specification |
|---|---|
| Official Model | VMIVME-7455 |
| Product Type | 6U VMEbus IDE CD-ROM Drive Module |
| Bus Standard | VMEbus 6U Eurocard, P2 backplane interface |
| Internal Interface | 40-pin IDE ribbon connector |
| CD Read Speed | Up to 40X maximum |
| IDE Transfer Rate | Up to 16 MB/s burst mode |
| Supported Media | CD-ROM, CD-R, CD-RW, multi-session, Enhanced CD, CD PLUS |
| Power Input | +5 V DC, ±12 V DC from VME backplane |
| Power Consumption | < 0.8 W idle; 7 W maximum during read |
| Operating Temperature | 0°C to +55°C (chassis ambient) |
| Storage Temperature | -40°C to +85°C |
| Form Factor | 6U single VME slot; 160 × 233.25 × 22 mm |
| Weight | 0.65 kg fully assembled |
| PCB Treatment | Conformal anti-corrosion coating |
| Compliance | CE Class A, MIL-STD-810 shock/vibration, industrial EMC |
GE VMIVME-7455
Application Fields
- Software loading and firmware distribution for VMEbus industrial automation control systems
- Program storage and data archiving for aerospace ground test and simulation platforms
- Turbine control and power generation system configuration and backup storage
- Shipboard and naval embedded VME system storage expansion
- Legacy VMEbus test and measurement system upgrade and retrofit
- Industrial embedded control system program distribution and version management
Related Model Recommendations
- VMIVME-7452: VMEbus floppy and hard disk storage module for combined magnetic and optical storage configurations.
- VMIVME-7459: Versatile mass storage module with optional CD-ROM, DVD, hard disk and CompactFlash options for higher capacity needs.
- VMIVME-7750: 6U VMEbus single-board computer that pairs with the VMIVME-7455 over the P2 backplane interface.
- VMIACC-0562: IDE signal adapter that converts P2 IDE signals into standard 40-pin and 34-pin connectors for external storage devices.
