Description
Product Overview
The GE IC698PSD300 is an industrial high-power 300W DC power supply module, specially developed for GE PACSystems RX7i PLC control systems. As the core power supply unit of RX7i rack equipment, it undertakes stable voltage conversion and multi-channel power distribution tasks. It provides reliable and continuous DC power for CPU modules, I/O modules, communication expansion modules and other rack accessories. It is a key component to ensure the normal startup, stable operation and safe shutdown of the entire industrial control system.
Power supply stability is the core foundation of long-term operation of industrial automation systems. Ordinary low-power power modules have limited load capacity and single protection function. They are prone to output voltage drift, overload shutdown and insufficient power supply when facing high-density module configuration. These problems easily cause system reset, signal disorder and production interruption. To solve these industrial operation pain points, the GE IC698PSD300 adopts high-efficiency power conversion circuit and industrial reinforced design. It supports wide-range DC input and multi-channel stable output, with complete fault monitoring and protection mechanisms. Every module passes strict full-load aging testing, parameter calibration and environmental resistance screening before delivery. It supports plug-and-play installation and system upgrade, and fully adapts to standardized global industrial e-commerce procurement modes.
Core Product Features & Competitive Advantages
Industrial PLC rack power supply determines the operating stability and service life of the whole set of control equipment. Ordinary universal power modules cannot adapt to high-load and long-cycle uninterrupted operation of medium and large industrial control systems. In contrast, the GE IC698PSD300 is customized for RX7i system racks. It integrates high-power output, multi-level safety protection and intelligent status monitoring, with outstanding industrial adaptability and operational reliability.
- 300W High-Rated Power Output: It supports maximum 300W total output power. It fully meets the power demand of full-equipped RX7i racks with multiple I/O and communication modules, solving the power shortage problem of low-power modules.
- Multi-Channel Regulated DC Output: It provides stable +5VDC, +12VDC and -12VDC multi-channel output. It accurately supplies power for different functional circuits inside the rack to ensure coordinated operation of all modules.
- Wide Input Voltage Adaptation: It adapts to 18–30VDC wide-range input voltage. It can resist slight voltage fluctuation on industrial sites and avoid system jitter caused by unstable input power.
- Complete Multi-Level Safety Protection: Built-in overvoltage, overcurrent, short-circuit and overtemperature protection functions. It automatically cuts off output power when faults occur to protect rack backplane and precision modules from damage.
- Intelligent Airflow & Temperature Monitoring: Equipped with professional airflow sensing and temperature detection modules. It monitors cooling status and operating temperature in real time, and triggers alarm for fan failure or poor heat dissipation.
- Standard Power Sequencing Function: It supports accurate power-on and power-off sequence control of RX7i backplane. It ensures orderly startup and shutdown of each module and avoids logic faults caused by inconsistent power supply timing.
- Visual Status Indication: Equipped with intuitive front-panel LED indicators. The green OUTPUT OK light shows normal operation, and the red OVER TEMP light prompts overheating fault, facilitating rapid on-site inspection.
- Excellent Industrial Compatibility: Standard single-width module design, perfectly matching Slot 0 of GE IC698 series RX7i racks. It supports direct replacement of old and faulty modules without rack modification or program debugging.
- High-Efficiency Energy-Saving Operation: Optimized power conversion circuit reduces heat generation and power loss. It supports 7×24 hours long-term full-load operation and reduces enterprise daily operation and maintenance costs.
Detailed Segmented Technical Specifications
The GE IC698PSD300 strictly complies with GE PACSystems industrial hardware standards and international industrial safety specifications. Its power conversion efficiency, output stability, electrical protection performance and environmental adaptability pass professional laboratory verification and long-term field operation tests. The classified detailed parameters below support accurate model selection, system matching, faulty module replacement and bulk engineering procurement.
3.1 Basic Product & Application Parameters
This high-power industrial power supply module is specially customized for GE RX7i PLC systems. It is widely used in new system construction, old equipment renovation and daily maintenance of industrial automation and power plant control systems.
- Official Product Model: IC698PSD300
- Product Category: Industrial Rack High-Power Supply Module
- Manufacturer: General Electric (GE Fanuc)
- Core Product Positioning: Rack DC power conversion, multi-channel power distribution, power sequence control, electrical fault protection, real-time operating status monitoring
- Fully Compatible System: GE PACSystems RX7i Series PLC, IC698 Series Rear-Mount Control Racks
- Installation Method: Standard plug-in installation, fixed in rack Slot 0
- Core Application Scenarios: New RX7i system construction, faulty power module replacement, high-load system upgrade, industrial automation equipment renovation, enterprise spare part strategic stocking
- Implementation Standards: GE industrial hardware specifications, CE safety certification, UL/cUL industrial certification, EMC electromagnetic compatibility standard
3.2 Core Electrical & Power Performance Parameters
The module adopts high-precision power conversion technology. It realizes stable wide-range input and multi-channel constant-voltage output, with efficient power conversion and strong load capacity.
- Nominal Input Voltage: 24VDC industrial standard voltage
- Working Input Voltage Range: 18VDC–30VDC wide adaptive range
- Typical Input Power: 430W
- Maximum Input Power: 550W
- Maximum Total Output Power: 300W full-load stable output
- Output Channel Configuration: +5VDC (0–50A), +12VDC (0–10A), -12VDC (0–4A)
- Hold-Up Time: Minimum 5ms stable power holding
- Power Ride-Through Time: Minimum 15ms voltage stabilization response
- Electrical Isolation Strength: 250VAC continuous isolation, 1500VAC 1-minute withstand voltage
- Output Stability: No voltage drift or power drop under long-term full-load operation
3.3 Protection & Monitoring Parameters
Equipped with comprehensive electrical protection and intelligent monitoring system. It can effectively prevent equipment damage caused by abnormal power supply and improve system operation safety.
- Protection Mechanism: Overvoltage protection, overcurrent protection, short-circuit protection, overtemperature automatic shutdown protection
- Cooling Monitoring Function: Built-in airflow sensor, real-time monitoring of cooling wind speed and ventilation status
- Status Indicator Lights: Green OUTPUT OK (normal power supply), red OVER TEMP (overheating alarm)
- Backplane Signal Interaction: Supports power sequencing signal and ACFAIL# fault feedback signal transmission
3.4 Mechanical & Structural Parameters
It adopts standard industrial modular structure and compact design. It features shock resistance and convenient installation, adapting to long-term cabinet vibration environment.
- Structural Type: Standard single-width RX7i plug-in module
- Cooling Mode: Forced air cooling (70 CFM standard airflow)
- Overall Weight: 1.88kg
- Installation Feature: Anti-loose plug-in design, firm contact, no poor connection caused by cabinet vibration
3.5 Environmental Adaptability Parameters
The module passes strict extreme environment tests. It maintains stable power supply performance in complex industrial cabinet environments.
- Full-Load Operating Temperature Range: 0°C to +60°C (with standard forced cooling)
- Storage Temperature Range: -40°C to +85°C ultra-wide temperature resistance
- Working Humidity Range: 5%–95% RH non-condensing environment
- Environmental Resistance: Dust-proof, moisture-proof, anti-electromagnetic interference, anti-surge impact
- Continuous Operation Capacity: Support 7×24 hours uninterrupted full-load industrial operation
3.6 Factory Testing & Quality Certification
All GE IC698PSD300 modules follow strict GE industrial quality management system. Each product completes full performance testing and aging verification before leaving the factory.
- Core Factory Test Items: Multi-channel output calibration, full-load aging test, protection function trigger test, airflow cooling test, high-low temperature cycle test, vibration resistance test, EMC electromagnetic compatibility test
- Quality Inspection Standard: 100% full-function detection + parameter precision calibration + complete test record filing
- Authoritative Qualification Certification: CE industrial safety certification, UL/cUL electrical certification, RoHS environmental certification
- Field Operation Performance: Widely applied in global industrial RX7i control systems, with ultra-low failure rate and long-term stable output performance
E-commerce Sales Mode & Complete Procurement Advantages
As the original high-power dedicated power supply for GE RX7i PLC systems, the GE adopts standardized and transparent global industrial e-commerce sales mode. It mainly serves industrial automation system construction, power plant control equipment maintenance, PLC system high-load upgrade and enterprise spare part reserve planning. It provides one-stop formal procurement and full-cycle professional technical after-sales services for manufacturing enterprises and engineering integrators.
4.1 Standardized Transparent E-commerce System
All products are 100% original genuine with complete traceable production, calibration and warehousing records. E-commerce platforms openly display official datasheets, factory test reports and qualification certificates. Buyers can verify product authenticity and core power performance parameters online at any time. This transparent sales model effectively avoids refurbished, modified and incompatible substitute power modules. It fully guarantees the power supply safety and operational stability of GE RX7i control systems.
4.2 Diversified Flexible Procurement Modes
Industrial system construction and maintenance projects have different cycle arrangements and quantity demands. We provide three flexible procurement solutions to cover all industrial application scenarios.
- Emergency Spot Procurement: Suitable for sudden power module failure, system power supply abnormality and production shutdown emergencies. Sufficient spot inventory supports rapid delivery. It quickly restores normal power supply of the control system and reduces enterprise downtime losses.
- Small-Batch Spare Part Stocking: Ideal for industrial enterprises to build GE RX7i series spare part inventory. Pre-storing this high-power power supply shortens emergency maintenance response time and improves system operation redundancy.
- Large-Batch Engineering Procurement: Provide customized preferential pricing and long-term framework cooperation agreements for large-scale automation system construction and batch equipment upgrade projects. It effectively reduces overall project procurement costs.
4.3 Full-Cycle After-Sales Service Guarantee
The rack power supply is the core energy supply unit of the entire PLC control system. Power module failure or performance attenuation will directly cause system paralysis and equipment shutdown. We provide comprehensive after-sales protection to eliminate all customer procurement risks.
- 100% Original Genuine Guarantee: All modules are genuine GE products with complete factory documents. It ensures 100% rack compatibility and consistent original factory power supply performance.
- Professional Industrial Packaging: Adopt anti-static, shockproof and moisture-proof integrated packaging. It protects internal precision circuits from damage during long-distance transportation and long-term storage.
- 24/7 Professional Technical Support: Provide pre-sales load calculation and model matching, installation guidance, power-on debugging and post-sales fault diagnosis full-process technical services.
- Long-Term Warranty Service: Unified official warranty coverage. Free repair and replacement for non-human-caused quality defects to reduce enterprise operation and maintenance costs.
Main Industrial Application Scenarios
With 300W high-power output, multi-channel stable power supply and complete safety protection, this module is widely used in construction, maintenance and upgrading of GE RX7i industrial control systems.
- New PLC System Construction: Serve as the core power supply unit for newly built RX7i automation racks. It provides stable and sufficient power support for full-module configuration of industrial control systems.
- Faulty Module Direct Replacement: Quickly replace aging, damaged and insufficient-output old power modules. It requires no system modification and realizes rapid recovery of system power supply function.
- High-Load System Upgrade: Match upgraded high-density I/O and communication modules. It solves the power bottleneck of low-power modules and improves system load capacity.
- Industrial Production Line Renovation: Applied in old automation production line renovation projects. It optimizes power supply stability and reduces system reset and signal fault rates.
- Enterprise Spare Part Reserve: Stored as key core spare parts for GE RX7i racks. It copes with sudden power supply faults and ensures continuous and safe operation of industrial production.
Product Value & Market Competitiveness
The GE solves the common defects of ordinary industrial power modules, such as insufficient power load, single protection function and poor environmental adaptability. It realizes 300W high-power stable output, multi-channel precise power distribution and intelligent fault monitoring protection. It greatly improves the power supply safety, load capacity and long-term operation stability of GE RX7i PLC control systems.
In the global industrial spare parts e-commerce market, this power supply module has prominent competitive advantages. It features original customized design for RX7i systems, wide voltage adaptation, industrial-grade full protection and low failure rate. Combined with genuine product guarantee, complete technical documents and full-cycle professional after-sales support, it has become the preferred power supply spare part for GE RX7i system construction, maintenance and high-load upgrade projects.
