GE DIGITALFLOW XMT868i Liquid flow transmitter

Description

Product Overview

The GE DigitalFlow XMT868i is a high-performance industrial ultrasonic liquid flow transmitter, developed by Panametrics (a GE Digital and Baker Hughes brand). It serves as a core process measurement device for industrial liquid flow monitoring and data acquisition. This transmitter supports both clamp-on and wetted transducer installation modes. It delivers accurate, repeatable and stable flow measurement for various acoustically conductive liquids. It is widely deployed in process industries that require continuous, non-intrusive or inline flow detection.

Traditional flow measurement devices have obvious limitations in complex industrial scenarios. Mechanical flow meters are prone to wear and blockage. They require regular maintenance and cannot handle liquids with bubbles or fine suspended solids. Conventional ultrasonic transmitters often feature narrow pipe size adaptation, single signal output and poor anti-interference capability. They suffer from data drift and low accuracy under variable temperature and pressure conditions. In addition, most ordinary transmitters lack multi-protocol communication support and flexible configuration functions. They cannot adapt to intelligent factory data collection and remote monitoring demands. The GE DigitalFlow XMT868i perfectly solves these industry pain points. It adopts advanced ultrasonic transit-time measurement technology, ultra-wide pipe size adaptation and multi-signal output design. Every unit undergoes strict factory calibration, full-condition performance testing and industrial environmental aging verification. It fully adapts to global industrial e-commerce procurement, old flow meter system upgrading and long-term 7×24-hour stable process monitoring.

Core Product Features & Competitive Advantages

Conventional industrial flow transmitters only complete basic flow data collection. They have weak scene adaptability, single functional configuration and insufficient data transmission capacity. They cannot meet high-precision measurement and intelligent data transmission requirements of modern process automation systems. In contrast, the GE DigitalFlow XMT868i is a professional multi-functional ultrasonic flow transmitter. It integrates dual installation compatibility, high-precision measurement, multi-protocol communication and industrial anti-interference performance. It greatly improves the accuracy, flexibility and intelligence level of industrial liquid flow monitoring.

• Dual Installation Mode Compatibility: Supports both non-intrusive clamp-on transducers and inline wetted transducers. The clamp-on mode requires no pipe cutting and no process shutdown. The wetted mode meets high-precision inline measurement demands. It adapts to diverse on-site installation conditions.
• Ultra-Wide Pipe Size Adaptation: Covers pipe sizes from 12.7 mm (0.5 inch) up to 7.6 m (300 inches) and larger. It fits small-branch pipelines and large-diameter main process pipelines. It eliminates the need for multiple types of flow meters in one production line.
• Strong Liquid Media Adaptability: Measures all acoustically conductive liquids stably. It works well with clean liquids and liquids containing tiny entrained solids or micro gas bubbles. It avoids measurement failure caused by medium impurities.
• High-Precision Transit-Time Measurement Technology: Adopts advanced ultrasonic transit-time algorithm. It realizes high-resolution flow detection and effectively reduces measurement errors. It ensures long-term stable and repeatable data output.
• Rich Multi-Protocol Communication Expansion: Equipped with standard RS232 interface and optional RS485, MODBUS, MODBUS/TCP, Ethernet and Foundation Fieldbus. It supports seamless docking with PLC, DCS and industrial intelligent management systems.
• Intelligent Local Display & Configuration: Features a 2-line 16-character backlit LCD screen. It displays multiple parameters including flow rate, cumulative flow and working status in real time. On-site parameter modification and status checking are convenient and efficient.
• Wide Power Supply Compatibility: Supports dual power input of 95–240 VAC and 12–28 VDC. It adapts to different industrial power distribution environments. It ensures stable power supply and continuous operation of equipment.
• Industrial-Grade Harsh Environment Resistance: Adopts high-strength industrial shell and optimized circuit shielding design. It resists high temperature, humidity, dust and electromagnetic interference. It supports stable operation in hazardous industrial areas.
• Zero Pipeline Pressure Loss: The clamp-on installation does not destroy pipeline structure. It causes no fluid pressure drop and no process flow resistance. It reduces production energy consumption and pipeline operation risks.
• Low Maintenance & Long Service Life: No mechanical moving parts inside. It avoids wear, blockage and frequent replacement problems. It greatly reduces later-stage operation and maintenance costs.

GE DIGITALFLOW XMT868i

Detailed Technical Specifications (Key Highlight Parameters)

The GE DigitalFlow XMT868i strictly follows GE Digital and Baker Hughes industrial process measurement standards. All measurement accuracy, electrical performance, structural indicators and environmental resistance parameters pass authoritative laboratory testing and long-term field verification. Its core advantages lie in ultra-wide adaptation, multi-mode installation, multi-protocol communication and high stability measurement. The sorted detailed parameters below support accurate engineering selection, process pipeline design and standardized batch procurement.

3.1 Basic Product Identification & Application Positioning

• Official Full Model: DigitalFlow XMT868i
• Brand Manufacturer: GE Digital / Panametrics (Baker Hughes)
• Product Type: Industrial Ultrasonic Liquid Flow Transmitter
• Core Functions: Real-time liquid flow rate measurement, cumulative flow statistics, multi-parameter display, industrial data communication, on-site status diagnosis
• Installation Forms: Clamp-on non-intrusive type / Wetted inline type
• Applicable Media: All acoustically conductive industrial liquids (clean water, chemical liquid, oil medium and liquids with micro impurities)
• Applicable Scenarios: Petrochemical processing, water treatment, power plant auxiliary monitoring, pharmaceutical production, food processing, industrial pipeline flow statistics and old flow measurement system upgrading
• Executive Standards: Industrial flow measurement calibration standards, international EMC electromagnetic compatibility standards, industrial explosion-proof and safety specifications

3.2 Core Measurement & Adaptation Parameters

This transmitter adopts optimized ultrasonic measurement algorithm. It features strong media adaptability and wide pipeline matching range. It maintains high-precision measurement output under complex process conditions.

• Measurement Principle: Ultrasonic transit-time differential method
• Applicable Pipe Size: 0.5 in (12.7 mm) to 300 in (7.6 m) and larger customized specifications
• Adaptable Medium: Clean liquids, liquids with suspended fine solids and micro gas bubbles
• Measurement Stability: Low data drift, excellent repeatability for long-term operation
• Working Mode: Single-channel / dual-channel optional measurement configuration
• Output Parameters: Instantaneous flow rate, cumulative flow, medium status diagnosis data

3.3 Electrical & Communication Parameters

The product supports dual power supply and rich industrial communication protocols. It meets diversified power supply conditions and intelligent data transmission demands of modern industrial automation systems.

• AC Power Supply: 95 VAC to 240 VAC, 50/60 Hz, ±10% tolerance
• DC Power Supply: 12 VDC to 28 VDC, ±5% tolerance (optional configuration)
• Maximum Power Consumption: 20 W
• Standard Interface: RS232 serial port (for local debugging and data output)
• Optional Interfaces: RS485, MODBUS RTU, MODBUS/TCP, Ethernet, Foundation Fieldbus
• Display Screen: 2-line × 16-character LCD with LED backlight, multi-parameter scrolling display
• Data Output Unit: Supports multiple units such as kg, ton, pound and cubic meter

3.4 Structural & Process Parameters

Matching different transducer accessories, the product supports diversified process connection methods. It adapts to high-pressure industrial pipeline working conditions and standardized on-site installation.

• Main Transducer Material: 316 stainless steel industrial anti-corrosion material
• Process Connection Specifications: 1-in NPTM, 3/8-in NPTM (standard); RF flange, socket weld (optional)
• Standard Pressure Resistance: 0.1013 MPa to 20 MPa (0–3000 psig)
• Custom Pressure Resistance: Support ultra-high pressure customization on request
• Structural Feature: Compact integrated transmitter design, easy field installation and fixing

3.5 Environmental Adaptability Parameters

The XMT868i passes strict industrial extreme environment tests. It maintains stable measurement performance and complete functional integrity in high-temperature, humid and high-interference factory environments.

• Operating Environment: Adapt to industrial indoor and outdoor process sites
• Anti-Interference Capability: Industrial-grade EMC shielding, resisting on-site electromagnetic crosstalk and power harmonic interference
• Working Characteristics: Dust-proof, moisture-proof and corrosion-resistant, suitable for long-term field operation
• Continuous Operation: Support 7×24-hour full-load uninterrupted measurement work

3.6 Factory Testing & Quality Certification

All devices are manufactured in strict accordance with GE Digital and Baker Hughes quality control systems. Each unit completes full-function calibration, communication testing and environmental aging screening before delivery to ensure consistent high performance.

• Core Certifications: Industrial measurement accuracy certification, CE electromagnetic compatibility certification, industrial safety qualification
• Factory Testing Items: Flow accuracy calibration, full-range communication protocol test, high and low temperature cycle test, pressure resistance test and long-term aging test
• Field Reliability: Widely applied in global process industrial sites, with ultra-low failure rate and long-term stable operation verification

GE DIGITALFLOW XMT868i

E-commerce Sales Mode & Complete Procurement Advantages

As a high-precision general-purpose industrial flow measurement device, the GE DigitalFlow XMT868i adopts standardized and transparent global industrial e-commerce sales mode. It focuses on new process pipeline flow monitoring construction, old flow meter system upgrading and enterprise industrial instrument strategic spare parts reserve. It provides one-stop standardized procurement and full-cycle professional technical services for process enterprises and engineering integrators.

4.1 Standardized Transparent E-commerce Sales System

All GE DigitalFlow XMT868i products implement unified original factory production and full-standard testing processes. The whole production, precision calibration and warehousing process is fully traceable. E-commerce platforms openly display complete product datasheets, measurement accuracy test reports and qualification certificates. Customers can verify product authenticity, measurement performance and protocol matching accuracy online. This transparent mechanism effectively avoids refurbished and inferior instruments. It ensures long-term accurate and stable operation of industrial flow monitoring systems.

4.2 Diversified Flexible Procurement Modes

Industrial on-site emergency maintenance, daily instrument spare parts stocking and new project construction have different demands for delivery cycle and procurement quantity. We provide flexible and targeted procurement solutions to cover all industrial application scenarios.

• Single Unit Emergency Spot Procurement: Support single spot orders for old flow transmitter failure, inaccurate measurement and data transmission abnormality. Sufficient global spot inventory supports fast delivery. It enables rapid on-site replacement and quickly restores normal flow monitoring of production pipelines.
• Small-Batch Spare Parts Stocking: Suitable for process enterprises to build instrument spare parts inventory. Pre-storing XMT868i transmitters improves on-site fault emergency response efficiency. It avoids production data missing and process adjustment errors caused by instrument failure.
• Large-Batch Engineering Procurement: Provide hierarchical preferential pricing and long-term framework cooperation services for new factory pipeline construction and old flow measurement system upgrading. It effectively reduces overall project procurement costs and shortens system installation and commissioning cycle.

4.3 Full-Cycle Value-Added Services & After-Sales Guarantee

The flow transmitter is the core data acquisition device of industrial process control systems. Its measurement accuracy and operational stability directly determine the authenticity of production data and the rationality of process parameter adjustment. We deliver full-cycle technical support and quality assurance to eliminate all procurement risks for industrial customers.

• 100% Original Genuine Quality Guarantee: All products are brand-new original GE DigitalFlow XMT868i ultrasonic flow transmitters with complete factory calibration reports and certification files. It ensures consistent measurement performance and system compatibility with original standard equipment.
• Professional Industrial-Grade Logistics Protection: Adopt multi-layer shockproof, moisture-proof and electrostatic-proof packaging. It protects internal precision sensors and circuit components from damage during long-distance transportation and storage.
• 24/7 Professional Technical Support: Provide pre-sales model selection and scheme matching consultation, in-sales installation guidance and parameter configuration, and after-sales data debugging and fault diagnosis services.
• Official Long-Term Warranty Service: Enjoy unified official after-sales warranty. Free replacement and maintenance services are available for non-human-induced quality faults to reduce enterprise instrument operation and maintenance costs.

Main Industrial Application Scenarios

Benefiting from dual installation flexibility, ultra-wide pipeline adaptation, strong medium tolerance and multi-protocol intelligent transmission capability, the GE DigitalFlow XMT868i is widely used in flow monitoring links of various process industries.

• Petrochemical Process Industry: Monitor flow parameters of chemical raw material liquids, intermediate media and finished product pipelines. It adapts to complex medium and high-interference workshop environments to ensure stable process production.
• Water Treatment & Municipal Engineering: Apply to water supply and drainage pipeline flow statistics, sewage treatment process monitoring and water resource consumption measurement. It supports long-term stable outdoor operation.
• Power Plant Auxiliary System: Monitor cooling water, desulfurization and denitrification liquid pipeline flow. It provides accurate data support for power plant energy consumption statistics and equipment operation adjustment.
• Pharmaceutical & Food Processing: Adopt non-intrusive clamp-on installation to avoid medium pollution. It meets sanitary production standards and realizes precise flow control of production media.
• Industrial Oil & Liquid Transportation: Measure flow of industrial oil and various industrial liquid media. It solves measurement difficulties of traditional meters for impurity-containing liquids.
• Old Flow Measurement System Upgrading: Replace aging mechanical flow meters and low-precision transmitters. It improves measurement accuracy and intelligent data transmission capability without large-scale pipeline reconstruction.

GE DIGITALFLOW XMT868i

Product Value & Market Competitiveness

The GE DigitalFlow XMT868i is a high-performance multi-scene ultrasonic liquid flow transmitter tailored for industrial process measurement. It fills the market gap of wide-adaptation, low-maintenance and intelligent ultrasonic flow measurement equipment. Compared with traditional mechanical and ordinary ultrasonic flow meters, it integrates dual installation modes, ultra-large pipe size coverage, strong impurity medium tolerance and multi-protocol intelligent communication. It solves core industry pain points such as easy blockage, narrow adaptation, high maintenance cost and single data transmission mode of traditional flow measurement devices.

In the global industrial instrument e-commerce market, the GE DigitalFlow XMT868i has prominent differentiated competitive advantages. It features zero pressure loss operation, wide power supply compatibility, strong harsh environment adaptability and long-term stable measurement performance. Combined with standardized genuine procurement, complete qualification documents and full-cycle professional technical services, it is the preferred core instrument for new construction, system upgrading and spare parts reserve of industrial liquid flow monitoring systems.
