Description
- Model: NDRIVECP30-S
- Type: Digital Servo Drive (Servo Amplifier)
- Brand: AEROTECH (Aerotech, Inc.)
- Series: AEROTECH NDRIVE Series Digital Servo Drive
- Input Voltage: 240 VAC (single-phase/3-phase, wide range: 180-264 VAC)
- Output Current: 30 A (continuous), 60 A (peak)
- Control Mode: Position control, speed control, torque control (switchable), with advanced PID control
- Response Bandwidth: Up to 1.5 kHz for fast motion tracking and dynamic performance
- Feedback Interface: Encoder interface (TTL/HTL), Sin/Cos encoder (optional), resolver interface (optional)
- Operating Temperature: 0°C to 45°C (no condensation)
- Storage Temperature: -20°C to +65°C
- Protection Class: IP20 (panel mounting, for industrial control cabinet installation)
- Weight: Approx. 5.2 kg (11.46 lbs)
- Dimensions: 150 mm × 230 mm × 320 mm (W×H×D), compact panel-mount design
- Certifications: CE, RoHS, UL
NDRIVECP30-S
Product Features
- Wide Input Voltage Adaptability: 180-264 VAC input supports single-phase and 3-phase power supply, adapting to diverse industrial power environments.
- High Current Output: 30A continuous/60A peak output efficiently drives high-power servo motors for heavy-load motion tasks.
- Multi-Control Modes: Switchable position, speed and torque control modes, combined with advanced PID algorithm for precise control.
- Fast Response Speed: 1.5 kHz response bandwidth ensures quick motion tracking, reducing position error and improving dynamic performance.
- Flexible Feedback Compatibility: Supports multiple feedback interfaces, meeting different precision requirements of servo control systems.
- Comprehensive Protection Functions: Built-in overcurrent, overvoltage, overheating, short-circuit and under-voltage protection, ensuring safe and stable operation.
- Easy System Integration: Compact panel-mount design and standard communication interfaces (EtherCAT optional) for simple integration into automated systems.
- High Control Precision: Digital control architecture and advanced control algorithm ensure high-accuracy positioning and speed regulation.
- Durable Industrial Design: Adopts industrial-grade components and rugged structure, suitable for long-term continuous operation in harsh industrial environments.
- User-Friendly Operation: Supports parameter configuration via software or front-panel buttons, with real-time status monitoring for easy debugging and maintenance.
Product Uses
- Servo Motor Drive: Provide stable and precise digital power drive for industrial servo motors.
- Precision Positioning Control: Realize high-accuracy position control for automated motion equipment and production lines.
- Speed & Torque Regulation: Maintain stable motor speed and adjustable torque to meet diverse load requirements.
- Multi-Axis Coordination: Integrate with AEROTECH motion controllers to achieve complex multi-axis synchronous motion control.
- Motion Synchronization: Ensure precise motion synchronization of multiple servo motors in automated production processes.
- Equipment Protection: Protect servo motors and related equipment from damage through built-in protection mechanisms.
- System Debugging & Maintenance: Convenient parameter configuration and status monitoring simplify system debugging and daily maintenance.
Application Fields
- Industrial Automation: Automated production lines, precision assembly equipment, material handling systems and multi-axis motion platforms.
- Precision Machining: CNC machine tools, milling machines, lathes and engraving machines for high-precision cutting and shaping.
- Robotics: Industrial robots, robotic arms and collaborative robots requiring precise motion control and multi-axis coordination.
- Semiconductor Industry: Semiconductor wafer handling, packaging, testing equipment and lithography machines.
- Aerospace: Aerospace component manufacturing, precision testing equipment and aviation motion simulation systems.
- Optical Manufacturing: Optical component processing, lens grinding, polishing equipment and laser processing systems.
- Medical Equipment: Precision medical devices, diagnostic equipment, automated medical systems and medical robot platforms.
- Electronics Manufacturing: PCB processing, microelectronic component assembly, testing equipment and electronic product precision assembly lines.
