The ABB 560PSU02, with exclusive factory part number 1KGT011900R0001, is a high-reliability industrial-grade DC power supply unit specially developed for the ABB RTU560 remote terminal unit series. As the core power distribution and conversion backbone of substation automation and industrial RTU system racks, this module is designed to convert wide-range substation DC battery voltage into stable 5VDC logic power and 24VDC peripheral power for RTU560 rack internal controllers, communication boards, I/O modules and field auxiliary equipment. It solves the common pain points of traditional power supplies such as narrow input voltage range, poor surge resistance and unstable output in substation battery power supply environments.
Adopting isolated switching power supply architecture and industrial-grade EMI filtering and surge suppression technology, the 560PSU02 1KGT011900R0001 supports ultra-wide 48VDC~220VDC full-range DC input, perfectly adapting to different voltage levels of substation battery banks. It features dual independent output channels, full electrical isolation, reverse polarity protection and redundant parallel current sharing capability. Undergoing strict factory full-load aging tests, substation power fluctuation simulation verification and standardized batch production, it is widely deployed in new substation automation project construction, old RTU system renovation, faulty power module replacement and batch engineering supporting procurement, fully meeting standardized and high-efficiency procurement demands of the global industrial e-commerce market.
ABB 560PSU02 1KGT011900R0001
Core Product Features & Competitive Advantages
Different from ordinary general industrial power supply modules, the ABB 560PSU02 (1KGT011900R0001) dedicated RTU power supply unit has prominent comprehensive advantages in wide voltage adaptation, operational stability, safety protection and redundant expandability. It provides continuous, stable and safe power guarantee for substation RTU automation systems, and its core competitive advantages are summarized as follows:
- Ultra-Wide Full-Range DC Input Adaptation: Supports 48VDC to 220VDC ultra-wide DC input range with -20%~+15% voltage fluctuation tolerance, covering all mainstream substation battery voltage specifications worldwide. It eliminates the need for customized power supply models for different substation projects, greatly simplifies model selection and inventory management and improves engineering versatility.
- Dual Independent Isolated Output Design: Integrates two dedicated DC output channels, including 5.1VDC high-current logic power for RTU core control chips and 24VDC auxiliary power for field sensors and communication peripherals. Dual-channel independent voltage regulation and isolation avoid mutual crosstalk between control power and peripheral power, ensuring stable operation of core control logic.
- Full Isolation & Strong Anti-Interference Performance: Adopts complete galvanic isolation between input and output stages, equipped with built-in high-grade EMI filter and surge suppression circuit. It effectively resists substation field voltage surge, power clutter and ground loop interference, ensuring zero-jitter and zero-drift stable output in harsh electromagnetic environments.
- Professional Multi-Dimensional Safety Protection: Built-in comprehensive protection mechanisms including reverse voltage protection, overvoltage protection, overcurrent limitation, short-circuit proof and electronic power limiting. It can automatically trigger protection locking and fault isolation under abnormal power conditions, effectively protecting RTU rack core modules from burnout damage and improving system operational safety.
- Redundant Parallel Current Sharing Capability: Supports multi-module redundant parallel operation and automatic balanced current sharing, which can be applied in high-availability RTU560MPR03 and 560SFR02 rack configurations. It realizes seamless power switching and zero downtime power supply backup, meeting ultra-high reliability power supply requirements of important substation automation systems.
- 50ms Ultra-Fast Voltage Ride-Through: Features excellent power interruption ride-through capability, maintaining continuous stable output within 50ms of 0% nominal voltage input interruption. It effectively avoids RTU system restart, data loss and communication disconnection caused by instantaneous power grid fluctuation and brief power failure.
- Exclusive RTU560 System Perfect Compatibility: Developed and verified exclusively for ABB RTU560 series remote terminal units, adopting standard 48-pin DIN 41612 backplane docking and matched pluggable terminal wiring. It supports plug-and-play installation without secondary parameter debugging, completely avoiding compatibility risks of generic power modules.
- Industrial-Grade Harsh Environment Durability: Selects high-temperature resistant and anti-aging industrial components, passing strict wide temperature cycle, vibration and mechanical impact tests. It adapts to -25℃~+70℃ wide temperature and high-humidity non-condensing environments, supporting 7×24-hour long-term uninterrupted full-load stable operation for substation unattended scenarios.
- Intuitive Status Diagnosis & Low Maintenance: Equipped with onboard LED status indicators for real-time monitoring of output power status and hardware faults. It supports rapid fault judgment and positioning, with simple daily maintenance and ultra-low field failure rate, reducing long-term operation and maintenance costs of power station equipment.
ABB 560PSU02 1KGT011900R0001
Detailed Technical Specifications (Key Highlight Parameters)
All technical parameters of ABB 560PSU02 (1KGT011900R0001) strictly comply with ABB substation automation equipment standards and international IEC power system device specifications. With ultra-wide voltage adaptation, dual-channel stable output, full safety protection and redundant expandability, it fully meets the technical requirements of substation RTU system construction, intelligent upgrading, faulty module replacement and batch standardized procurement. The classified detailed parameters are as follows:
3.1 Basic Product Identification & Classification
- Official Model: 560PSU02
- Exclusive Factory Part Number: 1KGT011900R0001
- Product Type: Industrial Isolated DC Power Supply Unit for RTU System
- Applicable Systems: ABB RTU560 Series Remote Terminal Units (560MPR03, 560SFR02 racks)
- Core Function: Wide-range DC power conversion, dual-channel stable power output, system power protection, redundant power backup and real-time power status monitoring
- Applicable Scenarios: Power substation automation, power grid monitoring, industrial remote monitoring, unattended power station and energy management systems
- Executive Standards: IEC 61010 power equipment safety standard, IEC 61000 EMC electromagnetic compatibility standard, ABB substation automation hardware specification
3.2 Core Input & Output Electrical Parameters
- Input Voltage Range: 48VDC ~ 220VDC ultra-wide full-range adaptation
- Input Voltage Tolerance: -20% ~ +15% wide fluctuation tolerance
- Total Maximum Output Power: 85W high-efficiency power conversion
- U1 Logic Output: 5.1VDC / 15A stable high-current output for core control circuit
- U2 Peripheral Output: 24VDC / 0.4A auxiliary power output for field peripherals
- Voltage Ride-Through Capacity: ≤50ms uninterrupted output at 0% nominal voltage interruption
- Conversion Efficiency: High energy-saving conversion rate, low heat generation under full-load operation
3.3 Protection & Isolation Performance Parameters
- Isolation Performance: Complete galvanic isolation between input and output stages, eliminating signal crosstalk and ground loop interference
- Input Protection: Reverse polarity protection, overvoltage protection and surge suppression protection
- Output Protection: Electronic power limiting, overcurrent protection and short-circuit proof automatic locking
- Internal Fuse: Built-in 4A T-type safety fuse; matched with 10A external circuit breaker for double protection
- Redundant Operation: Support multi-module parallel connection and automatic balanced current sharing
3.4 Interface & Mechanical Parameters
- Backplane Connection: 48-pin DIN 41612 standard industrial backplane connector
- Power Input Terminal: 3-pole 7.62mm pluggable screw terminal (included in delivery)
- Applicable Wire Gauge: 0.2mm² ~ 2.5mm² (AWG 24 ~ AWG 12)
- Installation Specification: 3HE Eurocard standard rack embedded installation
- Product Dimensions: 160mm × 100mm × 40mm compact standardized size
- Product Net Weight: 0.65kg lightweight industrial structure, convenient for installation and maintenance
3.5 Environmental Adaptability Parameters
- Operating Temperature Range: -25℃ ~ +70℃ industrial wide temperature working range
- Storage Temperature Range: -40℃ ~ +85℃ ultra-wide temperature storage tolerance
- Working Humidity: 5% ~ 95% non-condensing humidity environment
- Environmental Resistance: Dust-proof, moisture-proof and anti-corrosion, adapting to substation unattended harsh environments
- Mechanical Resistance: Passed industrial standard vibration and mechanical impact tests
3.6 Certification & Reliability Parameters
- Industrial Certifications: CE safety certification, ABB original factory quality certification, EMC electromagnetic compatibility certification
- Environmental Certification: RoHS environmental protection compliance certification
- System Compatibility: 100% matching with all ABB RTU560 series rack systems
- Continuous Operation: Support 7×24 hours long-term uninterrupted full-load stable operation
- Quality Reliability: Strict component screening and long-term full-load aging test, stable batch consistency and ultra-low field failure rate
ABB 560PSU02 1KGT011900R0001
E-commerce Sales Mode & Procurement Advantages
As a standardized core dedicated power supply unit for ABB substation automation systems, the ABB 560PSU02 (1KGT011900R0001) adopts a mature, transparent and standardized industrial e-commerce sales system. It supports global online inquiry, spot retail procurement, batch wholesale and engineering customized supporting services, providing one-stop reliable procurement solutions for power grid engineering companies, substation construction enterprises, automation system integrators and power equipment maintenance departments. All products are 100% original factory genuine with unified technical specifications, transparent pricing mechanism and full-cycle after-sales guarantee, effectively reducing enterprise procurement risks and comprehensive operational costs.
4.1 Standardized Transparent Online Sales System
This product implements unified global official technical parameters, standard industrial anti-vibration, dust-proof and moisture-proof professional packaging, and consistent global warranty policies. E-commerce platforms provide complete open resources including official datasheets, parameter manuals, redundant configuration guidelines, qualification certification documents and substation field application cases. The dual exclusive identification of 560PSU02 model and 1KGT011900R0001 part number supports official factory authenticity verification and full lifecycle traceability. It completely avoids refurbished, disassembled and counterfeit products, ensuring 100% system matching and power supply performance compliance for substation RTU automation systems.
4.2 Diversified Flexible Procurement Modes
- Single & Small-Batch Spot Retail: Support single-piece and small-quantity spot ordering, applicable to daily substation equipment maintenance, faulty RTU power module replacement, system debugging and old substation automation system renovation projects. Sufficient spot inventory ensures short delivery cycle and fast on-site system power recovery and commissioning.
- Bulk Wholesale & Framework Cooperation: Provide hierarchical preferential pricing and customized supply schemes for bulk orders from large power grid groups and engineering integration companies. Support long-term framework agreement cooperation, fixed-point stocking and stable batch supply, significantly reducing long-term batch procurement costs for substation RTU system spare parts.
- Engineering Customized Supporting Service: Provide professional model selection verification, redundant power scheme design and RTU rack matching consultation according to customers’ new substation construction, automation upgrading and old system renovation projects, realizing one-stop supporting procurement of 560PSU02 power modules and series system accessories.
4.3 Full-Cycle E-commerce Value-Added Services
- 100% Original Genuine Guarantee: All supplied products are original ABB factory genuine power supply units with complete factory test reports and qualification certificates, ensuring zero system matching error and zero power supply failure risk for substation core automation systems.
- Professional Industrial Logistics Protection: Adopt dedicated industrial anti-vibration, shockproof and moisture-proof customized packaging for precision power modules, support global multi-warehouse delivery, effectively preventing structural damage and circuit performance attenuation during long-distance transportation and handling.
- 24/7 Professional Online Technical Support: Provide pre-purchase model matching and power scheme consultation, mid-purchase installation guidance and redundant parallel configuration tutorials, and post-purchase fault diagnosis, power calibration and system debugging full-process technical services.
- Complete Official After-Sales Warranty: Enjoy unified global ABB official warranty service, support online after-sales application, quality problem replacement and professional technical maintenance guidance, reducing substation equipment failure downtime losses and long-term operation and maintenance costs.
ABB 560PSU02 1KGT011900R0001
Main Industrial Application Scenarios
Benefiting from its ultra-wide voltage adaptation, dual-channel stable output, full safety protection and redundant high-reliability operation, the ABB 560PSU02 (1KGT011900R0001) power supply unit is widely applied in core power supply links of substation and industrial remote monitoring automation systems, covering key fields as follows:
- Power Grid Substation Automation: Special power supply for remote terminal units in high-voltage, medium-voltage and low-voltage substations, providing stable logic and peripheral power for substation data acquisition, communication transmission and remote control equipment, ensuring long-term stable operation of unattended substations.
- Energy Power Monitoring System: Core power supply support for power plant remote monitoring, energy dispatching data acquisition and power quality monitoring equipment, adapting to complex battery power supply environments of power stations and improving the stability of energy monitoring systems.
- Industrial Remote Monitoring & Control: Power supply for industrial field remote terminal units and data acquisition equipment in petroleum, chemical, metallurgy and water treatment industries, resisting harsh industrial power fluctuation and electromagnetic interference, ensuring uninterrupted operation of remote monitoring systems.
- Smart Grid Construction Project: Supporting power supply for new smart substation RTU systems and grid edge monitoring equipment, meeting the high-reliability power supply requirements of intelligent grid data collection and remote interactive control.
- Old Power System Intelligent Renovation: Replacement and upgrading of aging power modules in old substation RTU systems, realizing wide-range voltage adaptation and redundant power backup, improving the overall stability and intelligent level of traditional power automation systems.
Product Value & Market Competitiveness
The ABB 560PSU02 (1KGT011900R0001) dedicated RTU power supply unit solves the core pain points of narrow input voltage range, single protection function, poor anti-interference and inability of redundant parallel operation of traditional industrial power modules. Its industry-leading 48~220VDC ultra-wide voltage design realizes full coverage of substation battery voltage levels, greatly simplifying engineering model selection and inventory management. The dual-channel isolated output and multi-dimensional safety protection mechanism effectively avoid RTU system equipment damage and operation failure caused by power abnormality.
In the global industrial e-commerce market, this ABB original exclusive power supply module features mature and stable switching power supply technology, reliable batch quality consistency and a large number of global power grid substation engineering application cases. Its exclusive system matching, redundant high-availability operation and industrial-grade harsh environment adaptability make it irreplaceable in substation automation construction, intelligent upgrading and faulty spare parts replacement projects. With strict genuine guarantee, comprehensive after-sales service system and low comprehensive operation and maintenance cost, it has become the preferred high-reliability power supply unit for global ABB system supporting and power grid intelligent renovation.
