Honeywell CC-PCF901 Control Firewall Module Product Introduction
The Honeywell CC-PCF901 (Part Number: 51405047-176) is an original industrial-grade Control Firewall Module exclusively designed for Honeywell Experion PKS Series C distributed control systems. Serving as a core network security and FTE (Fault Tolerant Ethernet) distribution component, this module acts as a critical isolation and data protection gateway for industrial control cabinets. It integrates industrial network firewall filtering, fault-tolerant Ethernet signal distribution, and internal cabinet network isolation functions, effectively isolating field I/O nodes from upper-level control networks. Adopting industrial network encryption technology and multi-layer signal protection architecture, it features high network transmission stability, powerful industrial anti-interference capability and professional safety isolation performance. It effectively prevents network data disorder, external intrusion and signal crosstalk, ensuring safe, stable and uninterrupted network communication of Honeywell PKS DCS systems in complex industrial environments.
HONEYWELL CC-PCF901
Core System Functions & Technical Mechanism
The CC-PCF901 module undertakes three core technical functions in the Experion PKS system: industrial network security isolation, FTE bus signal distribution and cabinet internal network management. Equipped with a standard 8-port downlink interface and 1-channel uplink interface, it supports centralized network distribution for multiple Series C FIM (Field Interface Module) devices inside the control cabinet. It can uniformly distribute upper-level FTE network signals to multiple on-site I/O modules, realizing standardized and orderly network wiring layout for DCS cabinets and avoiding network loop conflicts and signal confusion caused by traditional scattered wiring.
As a professional industrial control firewall unit, the module supports intelligent data filtering, access authority management and abnormal data interception. It automatically identifies and blocks illegal network access, abnormal data packets and external interference signals, effectively protecting the core control logic and process data of the DCS system from network attacks and signal pollution. In addition, it integrates comprehensive network self-diagnosis functions, capable of real-time monitoring network connection status, data transmission rate, port failure and link abnormality. It uploads network fault information to the upper Experion PKS host in real time, supporting rapid network troubleshooting and ensuring zero-delay synchronous transmission of industrial process control data.
Detailed Technical Specifications
Manufactured in strict accordance with Honeywell global industrial network safety standards and international industrial Ethernet specifications, the Honeywell CC-PCF901 has standardized and rigorous industrial technical parameters, fully adapting to long-term stable network operation of industrial DCS control systems. The core technical indicators are listed below:
- Official Part Number: CC-PCF901 / 51405047-176, dedicated control firewall and FTE distribution module for Honeywell Experion PKS Series C systems
- Port Configuration: 8 downlink FTE distribution ports + 1 uplink network port, supporting multi-device centralized network access
- Network Protocol: Fully compatible with Honeywell FTE fault-tolerant Ethernet protocol, supporting industrial high-speed real-time data transmission
- Security Mechanism: Built-in industrial firewall data filtering, access control and abnormal packet interception functions
- Installation Method: Matches CF9 IOTA termination assembly, standard cabinet embedded installation, plug-and-play replacement
- Working Voltage: Standard industrial 24VDC power supply, supporting wide-range voltage fluctuation adaptation
- Operating Temperature: Working temperature: -20°C to +70°C; Storage temperature: -40°C to +85°C, adapting to harsh industrial cabinet environments
- Environmental Adaptability: 0%–90% RH non-condensing humidity resistance, dust-proof and vibration-resistant industrial-grade design
- Anti-Interference Performance: Professional electromagnetic shielding structure, resisting industrial EMI interference and network signal attenuation
- System Compatibility: Perfectly matched with Honeywell Experion PKS C300 series controllers and supporting FIM modules
- Operational Performance: Low power consumption, high network transmission efficiency, supporting 7×24-hour uninterrupted network operation
