HIMA F8650X Product Introduction
- Model: F8650X
- Brand: HIMA (HIMA Paul Hildebrandt GmbH)
- Series: HIMA HIQuad X / HIMax Series
- Core Function: Safety logic control & fault diagnosis
- Type: CPU Module (Safety CPU Module)
- Key Specs: 5V/2A, SIL 3, Profinet/Modbus TCP
- Supply Status: in stock
- Stock: 14
- Warranty: 18 months
- Ship From: Europe
HIMA F8650X 984865065
Product System Function Introduction
1. Applicable SystemIt is mainly used in HIMA HIQuad X or HIMax Series safety PLC systems.It is also applied to industrial safety instrument systems (SIS).superscript:3superscript:5It is suitable for high-safety-requirement industrial automation scenarios.2. System RoleIt serves as the core component of the safety PLC and SIS systems.superscript:3superscript:5It executes preset safety control logic and emergency interlock commands.It monitors system status and triggers fault alarms promptly.superscript:5It ensures the safety of personnel, equipment and the production environment.superscript:33. Working PrincipleIt adopts a dual-clock synchronous 32-bit microprocessor architecture.superscript:2superscript:3It receives signals from field I/O modules and processes them in real time.It operates according to preset safety logic to output control instructions.It conducts self-diagnosis continuously and isolates single-point faults.superscript:2It transmits data and status information via standard communication protocols.superscript:2
HIMA F8650X 984865065
Physical Parameters (Size & Weight)
- Dimensions: 280mm × 120mm × 45mm
- Weight: Approximately 1.5kg
- Mounting: European standard 8 SU rack mounting
- Enclosure Material: High-strength industrial plastic
- Indicator Lights: 2 LED indicators for fault and operation status
- Protection Level: IP54, dust and water splash proof
Technical Specifications
- Processor: Intel 386EX 32-bit, 25MHz clock speed
- Memory: 1MB Flash-EPROM, 1MB SRAM per microprocessor
- Operating Temperature: -20℃ ~ 60℃, non-condensing
- Communication Interfaces: 2 isolated RS-485, 4 Gigabit Ethernet ports
- Safety Level: IEC 61508 SIL 3, Cat.4 safety grade
- Redundancy Design: Quadruple redundancy (QMR) architecture
- Standby Battery: CR 2477N, 2500 days life at 25℃
HIMA F8650X 984865065
Application Industries
- Oil & Gas Industry: Used in refineries and gas fields for safety interlock
- Chemical Industry: Applied to reactor safety control and emergency shutdown
- Power Industry: Protects key equipment in power generation and transmission
- Pharmaceutical Industry: Ensures safety of sterile production processes
- Metallurgical Industry: Adapts to high-temperature industrial environments
HIMA F8650X 984865065
Usage Instructions
- Installation: Mount on standard 8 SU rack, ensure good ventilation
- Wiring: Follow official diagrams, use shielded cables for communication
- Configuration: Use HIMA configuration software, set safety logic parameters
- Maintenance: Check indicators regularly, replace standby battery every 4 years
- Safety Notes: Cut off power before maintenance, only qualified technicians operate
