Description
- Model: PFEA113-20 3BSE050092R20
- Brand: ABB
- Series: ABB PFEA Pressductor Tension Control Series
- Core Function: Deliver high-precision industrial web tension monitoring and control
- Type: Tension Control Amplifier Module
- Key Specs: 24VDC operating voltage, dual sensor input, 15–1500ms step response
- Supply Status: In Stock
- Stock: Available
- Warranty: 12 months
- Ship From: China
ABB PFEA113-20 3BSE050092R20
Product System Introduction
The ABB PFEA113-20 3BSE050092R20 is a professional high-precision tension control amplifier module developed based on ABB’s mature Pressductor sensing technology. As a core signal processing and control unit in web tension automation systems, it is specially designed for continuous winding and unwinding production scenarios that require stable tension regulation. The module can perfectly cooperate with ABB tension sensors, PLC systems, servo drives and industrial host controllers to form a fully closed-loop tension control system. Widely applied in textile, papermaking, printing, packaging, steel strip and film production industries, it effectively solves common production problems such as material stretching, deviation and wrinkling caused by unstable tension, ensuring continuous and stable operation of automated winding production lines.
Product Functions
This advanced tension control module integrates high-precision signal acquisition, intelligent calculation and stable output regulation functions, focusing on accurate tension monitoring and dynamic adjustment of flexible materials. It supports dual-channel sensor signal input, which can independently collect real-time tension data from two sets of field Pressductor tension sensors, and accurately calculate the sum, difference and independent tension values of dual-channel signals through internal algorithms. The module features adjustable step response time ranging from 15ms to 1500ms, which can adapt to different production line speeds and material characteristics, realizing fast and smooth dynamic tension correction. It converts collected micro tension signals into standard industrial control signals, feeds them back to the upper automation system, and executes real-time adjustment of winding and unwinding tension. In addition, it has built-in signal filtering and fault diagnosis functions, which can automatically filter interference signals, monitor sensor working status and circuit abnormalities, and feed back fault prompts to avoid production quality defects and equipment failures caused by signal anomalies.
ABB PFEA113-20 3BSE050092R20
Product Features
ABB PFEA113-20 3BSE050092R20 boasts outstanding control accuracy, flexible adjustability and ultra-high industrial reliability, fully adapting to complex and high-precision industrial production requirements. Adopting ABB exclusive Pressductor signal processing technology, it captures tiny tension changes with ultra-high sensitivity, effectively improving finished product yield and production consistency. The multi-level adjustable response speed supports flexible matching of high-speed and low-speed production lines, with strong scene adaptability. It operates stably in a wide 18–36VDC voltage range, with low power consumption and strong resistance to industrial voltage fluctuation interference. The compact DIN rail mounting structure saves cabinet space and supports quick installation and wiring without complicated professional configuration. Equipped with complete signal protection and self-diagnosis functions, it can effectively prevent signal distortion and equipment damage. With long service life and excellent operational stability, it supports long-term uninterrupted continuous operation, and is compatible with new tension control systems and renovation and upgrade of old production lines.
Compatible & Recommended Products
To build a complete high-precision tension control system, we recommend matching ABB supporting products: ABB Pressductor tension sensors, industrial servo drive units and PLC control modules. These supporting devices achieve seamless signal docking and coordinated operation with PFEA113-20, realizing full-range closed-loop tension control, further optimizing production line operation stability and improving industrial production efficiency and product quality.
