ELAU C600/10/1/1/1/00 Product Introduction
- Model: C600/10/1/1/1/00
- Brand: ELAU (Schneider Electric)
- Series: ELAU PacDrive3 Series
- Core Function: Precision single-axis servo drive control
- Type: Servo Drive
- Key Specs: 3×400VAC, 10A, EtherCAT support
- Supply Status: in stock
- Stock: 17
- Warranty: 12 months
- Ship From: China
C600/10/1/1/1/00
System Application, Role & Working Principle
- Applicable System: It is mainly used in ELAU PacDrive3 industrial automation systems. It can also be integrated into PLC, DCS and motion control systems. It is widely applied in scenarios requiring high-precision and high-dynamic motion control[2].
- System Role: It serves as a core single-axis servo drive component in the system. It drives servo motors to achieve precise position, speed and torque control[2]. It reduces the burden on the upper controller and supports safe torque off (STO) to protect equipment and personnel safety[2].
- Working Principle: It receives control signals from the upper system via EtherCAT protocol[2]. It converts the input power (3×400VAC) into stable power suitable for servo motors[2]. It collects feedback signals from motors, forms a closed-loop control, and adjusts output in real time to ensure precise motion control[1].
C600/10/1/1/1/00
Application Industries
- Packaging Industry: Fillers, labelers and wrappers for high-speed and precise motion control[2].
- Printing Industry: Flexo and gravure presses to control roller synchronization and paper transmission[2].
- Electronics Manufacturing: PCB depaneling machines and component inserters for micron-level precision[2].
- Robotics: Small six-axis robots and robotic joints for stable motion drive[2].
Usage Instructions
- Installation: DIN rail mount in a ventilated cabinet, avoid strong electromagnetic interference and direct heat. Ensure IP20 protection requirements[2].
- Wiring: Follow the official diagram, connect 3×400VAC power and EtherCAT communication lines. Use shielded cables to reduce interference[2].
- Configuration: Program with ELAU professional software, set output current and communication parameters. Test closed-loop feedback before operation[2].
- Maintenance: Regularly check cable connections and temperature. Clean surface dust and inspect for overheating signs[2].
- Safety Notes: Cut off power before installation or maintenance. Ensure STO function is normal to avoid safety accidents[2].
